Tesla Powerwall handling equipment — Two people and a strap is how backs get hurt — this is the alternative.
A Powerwall 3 weighs 130 kg. Getting it out of a van, across a driveway and onto a wall bracket is the part of the job most likely to injure somebody or damage the unit, and it is the reason Tesla built a dolly specifically for it.
About the Tesla Powerwall handling equipment
The dolly connects directly to the battery — slide rails and a locking plate on a Powerwall 3, adjustable straps on a Powerwall 2 or Powerwall+ — and holds it through transit and placement. A lead screw lifting mechanism driven by a standard 18 to 20 V cordless drill through a 19 mm socket raises and lowers it with precision.
Pneumatic tyres and single-lever dual hydraulic disc brakes let it cross rough ground and go down stairs with the Powerwall secured, which is what makes awkward installations possible with one crew.
The ramp is the other half of the problem: a custom ramp made for unloading Powerwall 3 units from a vehicle, so the battery never has to be lifted down.
What does this fit?
This is the equipment that gets a 130 kg battery off the van and onto the wall.
The dolly fits all Powerwall models — slide rails and a locking plate on Powerwall 3, adjustable straps on Powerwall 2 and Powerwall+. The ramp is specific to unloading Powerwall 3 from a vehicle.
The products it is ordered with:
What the job needs
The details that decide whether this suits the system:
- Dolly maximum lift capacity is 136 kg, and maximum install height is 686 mm to the base of the Powerwall — 991 mm with the optional dolly platform.
- Lifting is by lead screw through a 19 mm (three-quarter inch) socket, driven by an 18 to 20 V battery drill. The drill is not included, and impact drivers must not be used.
- Brakes are single-lever, dual hydraulic disc. Tyres are pneumatic.
- Dolly dimensions are 1,690 × 593 × 461 mm at 24 kg, so plan the van space.
- Compatible with all Powerwall models: slide rails and locking plate for Powerwall 3, adjustable straps for Powerwall 2 and Powerwall+.
Where this earns its place
The Powerwall handling equipment is specified most often for these jobs.
Tesla Powerwall 3 Ramp technical data
Questions we get asked about this inverter
Is a drill included with the dolly?
No. It takes a standard 18 to 20 V cordless drill through a 19 mm socket, and impact drivers must not be used.
Which Powerwalls does the dolly fit?
All of them. Powerwall 3 connects by slide rails and a locking plate; Powerwall 2 and Powerwall+ use adjustable straps.
How high will it lift?
686 mm to the base of the Powerwall, or 991 mm with the optional dolly platform.
Can it go down stairs?
Yes, with the Powerwall secured — that is what the dual hydraulic disc brakes and pneumatic tyres are for.
