LONGi 520W Hi-MO X6 Max Explorer HPBC Half Cell Black Frame MC4-EVO2 Solar Panel
LONGi 520W Hi-MO X6 Max Explorer HPBC Half Cell Black Frame MC4-EVO2 Solar Panel
The LONGi Hi-MO X10 is an HPBC 2.0 back-contact solar panel. LONGi's HPBC back-contact cells carry no front-side busbars, so the whole front surface collects light and the module presents a uniform face. It delivers 23.0 % module efficiency from a 1,990 × 1,134 mm frame.
About the LONGi Hi-MO X10 range
Hi-MO X10 is LONGi's high-end residential platform. LONGi rates the HPBC 2.0 cell for higher generation from the same area, a gridline-free low-glare face, and an anti-shading function that limits localised overheating where part of the array is shaded.
At 1,990 × 1,134 mm it is a residential-format module, sized to fit the rafter spans and roof planes of a standard UK house.
Why installers specify this panel
- −0.280 %/°C power temperature coefficient — output falls away more slowly as the modules heat up through the middle of the day.
- Hail tested to 25 mm at 23 m/s — relevant for exposed and upland UK sites.
- All-black appearance — a black anodised frame and dark cells, for domestic roofs where the array has to be discreet.
- Long-dated warranty — 25-year power warranty; first-year degradation under 1 %, 0.40 % per year from year 2 to 25.
- 0 to +3 % power tolerance — every module is sorted to meet or beat its 520 W nameplate rating.
Electrical characteristics (STC)
| Rated power (Pmax) | 520 W |
| Module efficiency | 23.0 % |
| Open-circuit voltage (Voc) | 44.10 V |
| Voltage at maximum power (Vmp) | 37.24 V |
| Short-circuit current (Isc) | 14.95 A |
| Current at maximum power (Imp) | 13.97 A |
| Power tolerance | 0 to +3 % |
| Maximum system voltage | DC 1500 V (IEC) |
| Maximum series fuse rating | 25 A |
STC: AM1.5, 1,000 W/m², 25 °C cell temperature.
Mechanical specification
| Cell technology | HPBC 2.0 back-contact |
| Number of cells | 120 (6 × 20) |
| Glass | Single glass, 3.2 mm coated tempered |
| Frame | Anodised aluminium alloy |
| Dimensions (H × W × D) | 1,990 × 1,134 × 30 mm |
| Weight | 24.8 kg |
| Junction box | IP68 |
| Cable | 4 mm², ±1,400 mm |
Temperature and load ratings
| Temperature coefficient of Pmax | −0.280 %/°C |
| Temperature coefficient of Voc | −0.230 %/°C |
| Temperature coefficient of Isc | +0.050 %/°C |
| Operating temperature | −40 °C to +85 °C |
| Nominal operating cell temperature | 45 ±2 °C |
| Maximum static load | 5,400 Pa front / 2,400 Pa back |
| Hail test | 25 mm Hailstone at the speed of 23m/s |
| Hailstone test | 25 mm hailstone at 23 m/s |
| Protection class | Class II |
Warranty and certification
25-year power warranty; first-year degradation under 1 %, 0.40 % per year from year 2 to 25.
Array sizing
Each panel covers 2.26 m². A 4 kWp array needs 8 of them (4.16 kWp over about 18 m²). A 6 kWp array needs 12 of them (6.24 kWp over about 27 m²). Each module weighs 24.8 kg.
About LONGi
LONGi is one of the largest solar manufacturers in the world and the company behind the Hi-MO series. Its HPBC back-contact platform is the successor to the PERC modules it shipped in volume for a decade, and it is manufactured to IEC 61215 and IEC 61730 under ISO 9001, ISO 14001, ISO 45001 and IEC 62941 quality systems.
