Racky Rax Additonal Shelf
RackyRax Racky Rax Additonal Shelf
Racky Rax Additonal Shelf
RackyRax PowerCube battery rack — Built around the PowerCube H2 — and the BMU needs a shelf of its own.
A PowerCube string is a lot of weight in a small footprint, and it has to be supported at every module rather than stacked on itself. That is what these racks are for: a shelf per battery, in a frame designed around the PowerCube H2 rather than adapted from a network cabinet.
About the RackyRax PowerCube battery rack
Racky Rax build them to hold a full string, so the rack is chosen by the string length: eight batteries or twelve.
The detail that catches people out is the shelf count. A rack holds its string, but the BMU needs a shelf of its own, so a full rack plus BMU needs one additional shelf on top of the rack as listed. The -PACK versions have that shelf in the box already.
What does this fit?
This is the rack a Pylontech PowerCube H2 string is built in.
Designed around the Pylontech PowerCube H2 module (PYL-PC-H2-BATT). Choose the rack by string length, and remember the BMU needs a shelf of its own: a full rack plus BMU needs an additional shelf.
The products it is ordered with:
What the job needs
The details that decide whether this suits the system:
- Built for the Pylontech PowerCube H2, part PYL-PC-H2-BATT.
- RR-PC-13 holds a full string of twelve batteries; RR-PC-9 holds up to eight.
- An additional shelf (RR-PC-SHELF) is required for a full rack plus the BMU. It is not in the bare rack.
- The -PACK versions of both racks include that additional shelf.
- The PowerCube BMS on these systems is PYL-PC-SC1000-100-BMS.
- Check the floor loading. A full twelve-module PowerCube string in a rack is a substantial point load.
Where this earns its place
The rack is chosen by the length of the string.
RackyRax Additional shelf technical data
Questions we get asked about this inverter
Do I need the extra shelf?
If the rack is carrying a full string and the BMU, yes. The bare rack does not include it; the -PACK version does.
Which battery does it fit?
The Pylontech PowerCube H2, PYL-PC-H2-BATT.
How many batteries will it take?
RR-PC-13 takes a full string of twelve; RR-PC-9 takes up to eight.
Is the BMS included?
No. The PowerCube BMS, PYL-PC-SC1000-100-BMS, is a separate order.
Documents, advice and trade pricing
Every datasheet, certificate, installation manual and warranty document we hold for this product is in the Documents tab below. See the rest of our storage range, our hybrid inverters and our batteries, or email sales@clearraysolar.com if you would like us to check a pairing before you order.
