Solis Solar Package: Complete 5.4kWp Solar PV System for Maximum Efficiency

This Solis Solar package is a complete 5.4 kWp single-phase solar PV system built around the Solis S5 EH1P3.6K smart hybrid inverter and ten JA Solar 540W N-type TOPCon bifacial panels. It covers everything from roof anchors to generation metering in a single order, priced at trade for a typical UK plain-tile installation.

The Solis S5 hybrid platform runs at 97.5% efficiency with 160% PV input capacity and is battery-ready out of the box, so storage can be added later without changing the inverter. The JAM60D-42-540 panels deliver 23.1% module efficiency with double-glass bifacial construction and low-carbon traceable cells.

Mounting hardware is Clenergy PV-ezRack for plain tile roofs, with Projoy DC isolation, IMO AC isolation, Emlite bi-directional generation metering and all DC cabling, connectors and MCS-required labelling included.

What's Included

Inverter

• 1 × Solis S5 EH1P3.6K Smart Hybrid Inverter (SOL-S5-EH1P3.6K-S-UK) — 3.6kW · 97.5% — £493

Panels

• 10 × 540W JA Solar N-type TOPCon Bifacial (JAM60D-42-540-LB-TSLC-BF) — 23.1% efficiency — £765

Mounting (Plain Tile)

• 40 × Solar Roof Tegalit Anchor for Plain Tile — Clenergy · indicative quantity† — £254
• 6 × 4.6m Rail — Clenergy — £130
• 22 × Universal Module Clamp 30–46mm — Black — £63

Protection & Metering

• 1 × Projoy DC Isolator 32A 4-pole (2 string) — fit within 500mm of the inverter — £18
• 1 × AC Isolator 20A 1P — suitable up to 5kW — £15
• 1 × Emlite 1-ph Bi-Directional Generation Meter — £38
• 1 × DC Cable 4mm² 100m Black — Cableworld — £82
• 1 × DC Cable 4mm² 100m Red — Cableworld — £81

Consumables & BoS

• 20 × MC4 Female Connector 6mm² — £27
• 20 × MC4 Male Connector 6mm² — £21
• 1 × PV on Roof & Hazard Labels Pack — MCS 012 mandatory — £3
• 10 × Grounding/Bonding Spring — 1 per panel — £3

† Anchor quantity is indicative for a typical two-row plain tile layout — confirm against your roof survey.

Specifications

Key Features

• Complete system in one order — panels, inverter, mounting, isolation, metering, cabling and labels
• Solis S5 hybrid inverter with 160% PV input capacity and smart TOU-based energy management
• Battery-ready — add storage later without replacing the inverter
• N-type TOPCon bifacial panels with low-carbon traceable cells and double-glass construction
• MCS 012 mandatory labelling pack included
• Full 200m of 4mm² DC cable and 20 pairs of MC4 connectors for string wiring

Installation Notes

The DC isolator should be fitted within 500mm of the inverter. Mounting hardware is specified for plain tile roofs — anchor quantity is indicative and should be confirmed against the roof layout. One grounding/bonding spring is required per panel. The AC isolator supplied is rated for systems up to 5kW on single phase.
